TT ELECTRONICS / WELWYN Current Sense SMD Resistors

Намерете огромна гама от TT ELECTRONICS / WELWYN Current Sense SMD Resistors в Farnell България. Ние предлагаме широка гама от Current Sense SMD Resistors, като 0.005ohm, 0.01ohm, 0.001ohm & 0.02ohm от Tt Electronics / Welwyn

Изглед

Купувач

Инженер

В наличност(488)

Без доплащане за доставка(547)

Подходящо за нови проекти(623)

нов - 180 дни(14)

Date/Lot Code(569)

Съвместим с RoHS(627)

Производител

Resistance

Product Range

Resistor Case / Package

Power Rating

Resistance Tolerance

Resistor Type

Resistor Technology

Temperature Coefficient

Product Length

Product Width

Voltage Rating

Product Height

Operating Temperature Min

Operating Temperature Max

Qualification

Опаковка

Приложен(и) филтър(и)

Производител

TT ELECTRONICS / WELWYN

1 Избран(и) филтър(и)

			Цена за		Количество

MFC0603-R007FT5	2765604 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.007 ohm MFC Series 0603 [1608 Metric] 500 mW ± 1% Metal Foil	Each (Supplied on Full Reel) Цели бобини Опции за опаковка	5000+ € 0,118	Мин: 5000 / Множ: 5000	0.007ohm	MFC Series	0603 [1608 Metric]	500mW	± 1%	-	Metal Foil	± 50ppm/°C	1.6mm	0.85mm	-	0.85mm	-55°C	155°C	-
MFC0805-R10FT5	3782209 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.1 ohm MFC Series 0805 [2012 Metric] 750 mW ± 1% Metal Foil	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,437 100+ € 0,391 500+ € 0,284 1000+ € 0,211 2500+ € 0,207 Още цени...	Мин: 10 / Множ: 10	0.1ohm	MFC Series	0805 [2012 Metric]	750mW	± 1%	-	Metal Foil	± 50ppm/°C	2.01mm	1.25mm	-	0.85mm	-55°C	155°C	AEC-Q200
MFC0805-R10FT5	3782209RL Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.1 ohm MFC Series 0805 [2012 Metric] 750 mW ± 1% Metal Foil	Each (Supplied on Cut Tape) Пренавиване Опции за опаковка	100+ € 0,391 500+ € 0,284 1000+ € 0,211 2500+ € 0,207 5000+ € 0,203	Мин: 100 / Множ: 10	0.1ohm	MFC Series	0805 [2012 Metric]	750mW	± 1%	-	Metal Foil	± 50ppm/°C	2.01mm	1.25mm	-	0.85mm	-55°C	155°C	AEC-Q200
LR1206-R50FW	1100339 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.5 ohm LR Series 1206 [3216 Metric] 500 mW ± 1% Thick Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,110 50+ € 0,603 250+ € 0,558 500+ € 0,512 1500+ € 0,402	Мин: 5 / Множ: 5	0.5ohm	LR Series	1206 [3216 Metric]	500mW	± 1%	General Purpose	Thick Film	± 100ppm/°C	3.2mm	1.6mm	200V	0.8mm	-55°C	150°C	AEC-Q200
ULR2-R001FT2	1292489 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.001 ohm ULR Series 2512 [6432 Metric] 2 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 0,658 50+ € 0,482 250+ € 0,362 500+ € 0,293 1000+ € 0,236 Още цени...	Мин: 5 / Множ: 5	0.001ohm	ULR Series	2512 [6432 Metric]	2W	± 1%	-	Metal Strip	± 50ppm/°C	6.35mm	3mm	-	0.6mm	-55°C	170°C	AEC-Q200
LRF2512-R025FW	1100061 Data Sheet RoHS	TT ELECTRONICS / WELWYN RES 0R025 1% 2W 2512 THICK FILM	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	1+ € 1,680 50+ € 0,809 100+ € 0,736 250+ € 0,622 1000+ € 0,621 Още цени...	Мин: 1 / Множ: 1	0.025ohm	LRF Series	2512 [6432 Metric]	2W	± 1%	General Purpose	Thick Film	± 100ppm/°C	6.5mm	3.25mm	-	0.84mm	-55°C	150°C	AEC-Q200
LRF1206-R005JW	1099906 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.005 ohm LRF Series 1206 [3216 Metric] 500 mW ± 5% Thick Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 0,989 50+ € 0,567 250+ € 0,381 500+ € 0,323 1500+ € 0,280 Още цени...	Мин: 5 / Множ: 5	0.005ohm	LRF Series	1206 [3216 Metric]	500mW	± 5%	General Purpose	Thick Film	± 100ppm/°C	3.2mm	1.6mm	-	0.8mm	-55°C	150°C	AEC-Q200
LRMAT2512-R005FT4	2079417 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.005 ohm LRMA Series 2512 [6432 Metric] 2 W ± 1% Metal Alloy	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,429 100+ € 0,297 500+ € 0,271 1000+ € 0,242 2000+ € 0,213	Мин: 10 / Множ: 10	0.005ohm	LRMA Series	2512 [6432 Metric]	2W	± 1%	-	Metal Alloy	± 100ppm/°C	6.4mm	3.2mm	-	0.65mm	-55°C	170°C	-
LRCS0805-0R5FT5	1506145 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.5 ohm LRCS Series 0805 [2012 Metric] 250 mW ± 1% Metal Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,299 100+ € 0,129 500+ € 0,0925 1000+ € 0,081 2500+ € 0,0734 Още цени...	Мин: 10 / Множ: 10	0.5ohm	LRCS Series	0805 [2012 Metric]	250mW	± 1%	-	Metal Film	± 300ppm/°C	2.01mm	1.25mm	-	0.55mm	-55°C	155°C	-
LRMAM1206-R01FT5	2079442 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.01 ohm LRMA Series 1206 [3216 Metric] 1 W ± 1% Metal Alloy	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,429 100+ € 0,257 500+ € 0,242 1000+ € 0,228 2500+ € 0,213	Мин: 10 / Множ: 10	0.01ohm	LRMA Series	1206 [3216 Metric]	1W	± 1%	-	Metal Alloy	± 50ppm/°C	3.2mm	1.6mm	-	0.6mm	-55°C	170°C	AEC-Q200
LRF2512-R01FW	1100058 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.01 ohm LRF Series 2512 [6432 Metric] 2 W ± 1% Thick Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	1+ € 1,680 50+ € 0,802 100+ € 0,694 250+ € 0,585 1000+ € 0,519	Мин: 1 / Множ: 1	0.01ohm	LRF Series	2512 [6432 Metric]	2W	± 1%	General Purpose	Thick Film	± 100ppm/°C	6.5mm	3.25mm	-	0.84mm	-55°C	150°C	AEC-Q200
LRF1206-R01FW	1099907 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.01 ohm LRF Series 1206 [3216 Metric] 500 mW ± 1% Thick Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,290 50+ € 0,604 250+ € 0,521 500+ € 0,458 1500+ € 0,395	Мин: 5 / Множ: 5	0.01ohm	LRF Series	1206 [3216 Metric]	500mW	± 1%	General Purpose	Thick Film	± 100ppm/°C	3.2mm	1.6mm	-	0.8mm	-55°C	150°C	AEC-Q200
LRMAM1206-R025FT5	2079439 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.025 ohm LRMA Series 1206 [3216 Metric] 1 W ± 1% Metal Alloy	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,419 100+ € 0,268 500+ € 0,250 1000+ € 0,231 2500+ € 0,213 Още цени...	Мин: 10 / Множ: 10	0.025ohm	LRMA Series	1206 [3216 Metric]	1W	± 1%	-	Metal Alloy	± 75ppm/°C	3.2mm	1.6mm	-	0.6mm	-55°C	170°C	AEC-Q200
LRMAM1206-R005FT5	2079443 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.005 ohm LRMA Series 1206 [3216 Metric] 1 W ± 1% Metal Alloy	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,419 100+ € 0,255 500+ € 0,241 1000+ € 0,227 2500+ € 0,213	Мин: 10 / Множ: 10	0.005ohm	LRMA Series	1206 [3216 Metric]	1W	± 1%	-	Metal Alloy	± 100ppm/°C	3.2mm	1.6mm	-	0.6mm	-55°C	170°C	AEC-Q200
ULR2-R01FT2	1292496 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.01 ohm ULR Series 2512 [6432 Metric] 2 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,530 50+ € 0,668 250+ € 0,504 500+ € 0,503 1000+ € 0,502 Още цени...	Мин: 5 / Множ: 5	0.01ohm	ULR Series	2512 [6432 Metric]	2W	± 1%	-	Metal Strip	± 50ppm/°C	6.35mm	3mm	-	0.6mm	-55°C	170°C	AEC-Q200
ULR1S-R008FT2	1621974 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.008 ohm ULR Series 1206 [3216 Metric] 1 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,320 50+ € 0,798 250+ € 0,679 500+ € 0,607 1000+ € 0,534 Още цени...	Мин: 5 / Множ: 5	0.008ohm	ULR Series	1206 [3216 Metric]	1W	± 1%	-	Metal Strip	± 50ppm/°C	3.2mm	1.6mm	-	0.6mm	-55°C	170°C	AEC-Q200
LRMAP2512-R01FT4	2079429 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.01 ohm LRMA Series 2512 [6432 Metric] 3 W ± 1% Metal Alloy	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,621 100+ € 0,574 500+ € 0,465 1000+ € 0,366 2000+ € 0,292	Мин: 10 / Множ: 10	0.01ohm	LRMA Series	2512 [6432 Metric]	3W	± 1%	-	Metal Alloy	± 50ppm/°C	6.4mm	3.2mm	-	0.65mm	-55°C	170°C	-
OARS1 - R025FI	1200352 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.025 ohm OARS Series SMD 2 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	1+ € 3,010 50+ € 0,863 100+ € 0,798 250+ € 0,732 1000+ € 0,554 Още цени...	Мин: 1 / Множ: 1	0.025ohm	OARS Series	SMD	2W	± 1%	-	Metal Strip	± 20ppm/°C	11.18mm	3.18mm	-	3.05mm	-40°C	125°C	AEC-Q200
OARS-XP-0R002	1292585 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.002 ohm OARS-XP Series SMD 3.5 W ± 5% Metal Strip	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	1+ € 4,650 50+ € 1,790 100+ € 1,520 250+ € 1,320 500+ € 1,150 Още цени...	Мин: 1 / Множ: 1	0.002ohm	OARS-XP Series	SMD	3.5W	± 5%	-	Metal Strip	± 40ppm/°C	-	6.01mm	-	-	-55°C	125°C	AEC-Q200
LRF1206-R025FW	1099910 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.025 ohm LRF Series 1206 [3216 Metric] 500 mW ± 1% Thick Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,370 50+ € 0,582 250+ € 0,425 500+ € 0,358 1500+ € 0,333 Още цени...	Мин: 5 / Множ: 5	0.025ohm	LRF Series	1206 [3216 Metric]	500mW	± 1%	General Purpose	Thick Film	± 100ppm/°C	3.2mm	1.6mm	-	0.8mm	-55°C	150°C	AEC-Q200
ULR3-R001FT2	1292506 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.001 ohm ULR Series 2512 [6432 Metric] 3 W ± 1% Metal Strip	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,810 50+ € 0,806 250+ € 0,610 500+ € 0,602 1000+ € 0,593	Мин: 5 / Множ: 5	0.001ohm	ULR Series	2512 [6432 Metric]	3W	± 1%	-	Metal Strip	± 50ppm/°C	6.35mm	3mm	-	0.6mm	-55°C	170°C	AEC-Q200
LRF2512-R02FW	1100060 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN RES 0R02 1% 2W 2512 THICK FILM	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	1+ € 1,680 50+ € 0,871 100+ € 0,804 250+ € 0,702 1000+ € 0,583	Мин: 1 / Множ: 1	0.02ohm	LRF Series	2512 [6432 Metric]	2W	± 1%	General Purpose	Thick Film	± 100ppm/°C	6.5mm	3.25mm	-	0.84mm	-55°C	150°C	AEC-Q200
LR1206-R05FW	1099913 Data Sheet RoHS	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.05 ohm LR Series 1206 [3216 Metric] 500 mW ± 1% Thick Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	5+ € 1,310 50+ € 0,619 250+ € 0,410 500+ € 0,339 1500+ € 0,325 Още цени...	Мин: 5 / Множ: 5	0.05ohm	LR Series	1206 [3216 Metric]	500mW	± 1%	-	Thick Film	± 100ppm/°C	3.2mm	1.6mm	200V	-	-55°C	150°C	AEC-Q200
LRCS0805-0R07FT5	1506141 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.07 ohm LRCS Series 0805 [2012 Metric] 125 mW ± 1% Metal Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,534 100+ € 0,329 500+ € 0,237 1000+ € 0,209 2500+ € 0,180 Още цени...	Мин: 10 / Множ: 10	0.07ohm	LRCS Series	0805 [2012 Metric]	125mW	± 1%	-	Metal Film	± 400ppm/°C	2.01mm	1.25mm	-	0.55mm	-55°C	155°C	-
LRCS0805-0R1FT5	1506142 Data Sheet RoHS Date/Lot Code	TT ELECTRONICS / WELWYN SMD Current Sense Resistor 0.1 ohm LRCS Series 0805 [2012 Metric] 250 mW ± 1% Metal Film	Each (Supplied on Cut Tape) Прекъсната лента Опции за опаковка	10+ € 0,578 100+ € 0,347 500+ € 0,310 1000+ € 0,274 2500+ € 0,237	Мин: 10 / Множ: 10	0.1ohm	LRCS Series	0805 [2012 Metric]	250mW	± 1%	-	Metal Film	± 400ppm/°C	2.01mm	1.25mm	-	0.55mm	-55°C	155°C	-
