FLUKE-368 FC

The Fluke 368 FC true-rms leakage current clamp meter helps users detect, document, record and compare leakage current readings over time as a means of preventing unplanned downtime, and identifying intermittent GFCI and RCD trips, all without taking equipment off line. The Fluke 368 FC has a large 40 mm diameter jaw for work with large conductors. The clamp’s jaw is fully shielded to accurately capture very small leakage signals, and to minimize external electromagnetic interference. The 368 FC also offers wireless data connectivity via Fluke Connect.

• True-rms measurements for accuracy when measuring complex, non-sinusoidal waveforms
• 40 mm jaw opening
• Highest resolution of 1 μA, measure up to 60 A
• Selectable filter function removes unwanted noise
• Max/Min/Average readings and hold function
• Forward-facing LED worklight for use in dark wiring cabinets
• Backlit display; auto backlight off and auto power off for extended battery life
• CAT III 600V safety rating
• Internal Memory Logging: up to 65,000 measurement points

Съдържание

Earth Ground clamp, Hard case, Loop resistance standard, 4 AA batteries, Safety information guide, Quick reference guide

Бележки

Calibration services are available (Europe only). Please visit our calibration services page for more details.
